The digital multimeter with temperature probe is an essential tool for every technician. This versatile device supports a wide range of measurements, ensuring accuracy and reliability.
Key Features:
- Triple continuity test signal: sound (buzzer 0.5s), numeric display.
- High range for DC current and voltage measurement (20A/1000V).
- Automatic switch-off feature to prevent battery drain.
- Convenient measurement range for small DC currents (2mA).
- Last measurement memory function with HOLD "H" button.
- Capacitor measurement capability (6 ranges up to 200µF).
- Rubber holster for protection against mechanical damage and electric shock.
- Compliant with IEC-1010 standard for electronic measuring instruments, Overvoltage Category CAT II / CAT III, and Pollution Degree 2.
- CE certified product.
Measurement Capabilities:
- DC and AC voltage measurement.
- DC and AC current measurement.
- Resistance measurement.
- Capacitor measurement.
- Transistor hFE measurement.
- Diode forward voltage measurement.
- Circuit continuity check.
- Temperature measurement.
Technical Specifications:
- DCV: 200m/2/20/200/1000V +/-(0.5%+1)
- ACV: 200mV +/-(1.2%+3), 2/20/200V +/-(0.5%+1), 750V +/-(1.2%+5)
- DCA: 2mA +/-(0.8%+1), 20mA +/-(1%+3), 200mA +/-(1.2%+1), 20A +/-(2%+5)
- ACA: 20mA +/-(1%+3), 200mA +/-(1.8%+3), 20A +/-(2%+5)
- OHM: 200Ω +/-(0.8%+3), 2k/20k/200k/2MΩ +/-(0.8%+1), 20MΩ +/-(1%+2)
- CAP: 2n/20n/200n/2µ/200µF +/-(4%+3)
- TEMP: -40°C to 400°C +/-0.75% (+/-3), 400°C to 1000°C +/-1.5% (+/-5)
- FREQUENCY: 200kHz +/-1.5% (+/-10)
- Transistor test: Yes
- Automatic switch: Yes
- Diode test: Yes
- Circuit continuity indicator: Yes
- LCD Display: Yes
- Battery: 9V 6F22
- Net weight: 300g
- Display range: 1-999
- Display size: 33x63mm
- Dimensions: 91x189x32mm
Package Includes:
- Brand new digital multimeter
- Complete set of measurement leads
- Temperature probe lead
- 9V 6F22 battery
- Original packaging
Product is new, unused, and securely packaged.
