A practical angle magnet for welding and assembly that enables quick positioning of material at precise angles of 105°, 125°, and 140°. Compact dimensions of 95 × 64 mm, a robust steel housing, and a load capacity up to 9 kg in the vertical direction ensure reliable and safe holding of steel parts.
The angle welding magnet is an indispensable aid for precise positioning and fixing of sheets, profiles, and tubes during welding, brazing, or assembly. The permanent magnet in a durable steel housing guarantees stable holding of the material without the need for clamps.
Thanks to the predefined angles of 105° / 125° / 140°, you can easily achieve repeatable and precise joint geometry. In the vertical direction, the magnet holds steel parts up to 9 kg (at the center of gravity); when deviating from the vertical position, the load capacity naturally decreases down to shear.
- Quick positioning of material without tools
- Stable fixation thanks to the permanent magnet
- Durable steel housing for long service life
- Compact dimensions 95 × 64 mm for work even in confined spaces
Specifications
- Type
- Angle welding magnet
- Magnet
- Permanent
- Dimensions
- 95 × 64 mm
- Preset angles
- 105°, 125°, 140°
- Load capacity (vertical, at center of gravity)
- 9 kg
- Housing material
- Steel
- Suitable materials
- Steel / iron
- Applications
- Welding, brazing, assembly, and part holding
