The professional LaserPecker LP4 Safeguard laser engraving machine combines a dual laser 450 nm + 1064 nm, speed up to 4000 mm/s, and ultra precision of 0.01 mm. Thanks to the Class I enclosed housing, intelligent preview, and efficient smoke extraction, you can engrave safely, quickly, and in top quality on over 300 materials.
One machine for endless creativity. The dual laser (10 W blue 450 nm + 2 W IR 1064 nm) handles over 300 materials—wood, leather, paper, acrylic, metals, and stainless steel. The LP4 Safeguard offers 8K resolution and line precision of 0.01 mm for fine details, logos, and technical markings.
Speed and efficiency. Engraving at up to 4000 mm/s significantly shortens production time and boosts productivity for batches. The smart work area preview and automatic parameter recommendations minimize errors and speed setup when changing materials.
Safety and clean operation. A fully enclosed Class I cover with a Hall sensor, emergency STOP, and advanced filtering (190–550 nm and 800–1100 nm) protect the user. Intelligent extraction with automatic RPM control and an air purifier with 99% efficiency ensure low noise (~55 dB) and a clean working environment.
- Dual source: 450 nm diode 10 W + 1064 nm IR 2 W
- Resolution up to 8K and 0.01 mm line precision
- Engraving speed up to 4000 mm/s
- Class I safety, enclosed housing, emergency STOP
- Smoke extraction + air purifier with 99% filtration
- Rectangle/center-point preview and smart parameter recommendations
- Supports 300+ materials including stainless steel
- Compatibility with LightBurn, iOS/Android/Windows/macOS
Specifications
- Manufacturer
- LaserPecker
- Model
- LP4-SV
- Dimensions
- 282 × 290 × 407 mm
- Weight
- 6.75 kg
- Laser source and power
- 1064 nm infrared laser (2 W) and 450 nm diode laser (10 W)
- Working area
- 160 × 120 mm (ellipse) / 100 × 100 mm (square)
- Exterior material
- Aluminum alloy + plastic composite
- Preview mode
- Rectangle preview / center-point preview
- Supported file formats
- PC: G-code / JPG / PNG / BMP / SVG / DXF etc.; Mobile app: G-code / JPG / PNG / SVG
- Connectivity
- USB and Bluetooth 5.0
- Supported operating systems
- iOS 13.0+, Android 7.0+, macOS 10.15+, Windows 10+, compatible with LightBurn
- Input power
- DC 24 V, 5 A; AC 100–240 V, 50–60 Hz; 120 W
- Ambient temperature and humidity
- Temperature 0–65 °C; humidity 5–80% RH (non-condensing)
- Safety certifications
- CE, RoHS, FCC, FDA, NCC, KC, UKCA, TELEC, SRRC
- Max. engraving height with universal electric roller
- LP4: 55 mm
- Safety
- Class I enclosed cover, Hall sensor, emergency stop, filtration 190–550 nm and 800–1100 nm
- Noise
- ≈55 dB (air purifier)
